Internal vacuum lifters
Technical specifications
Inquire now
D-12V
Does not meet the requirements for site operation according to DIN EN 13155.
1-circuit system
1 vacuum circuit
Suction pad
depending on the suction frame
Load capacity
300 kg
Turn
360° manual, lockable every 45
Sway
No
Power supply
12 V battery mains-independent with integrated charger
Furnishing
- Voltage indicator, shows the battery charge level
- Vacuum display, shows the current vacuum level
- Acoustic warning signal when vacuum is undershot
Service
Suction-release button or hand valve on the device
Own weight
depending on the suction frame
