Internal vacuum lifters
Technical specifications
Inquire now
MDKG-400V
Does not meet the requirements for site operation according to DIN EN 13155.
1-circuit system
1 vacuum circuit
Suction pad
depending on the suction frame
Load capacity
300 kg
Turn
360° electric
Sway
No
Power supply
Mains operation 400 V
Furnishing
- Vacuum display, shows the current vacuum level
- Acoustic warning signal when vacuum is undershot
- Transport: vertical
Service
Suction-release button on the device; rotate button on the device; option: Crane control on the device
Own weight
depending on the suction frame
Options
The MDKG-400V can be combined with many special suction frames.
