Internal vacuum lifters
Technical specifications
Inquire nowTR-V
Does not meet the requirements for site operation according to DIN EN 13155.
1-circuit system
1 vacuum circuit
Suction pad
10 pieces, type 150K
Load capacity
1500 kg
Turn
No
Sway
No
Power supply
400 V mains operation
Furnishing
- Vacuum display, shows the current vacuum level
- Acoustic warning signal when vacuum is undershot
- Iso holder
- Transport vertical
Service
Cable remote control
Options
The TR-V is available on request in many different variants in terms of frame size, load capacity, operation and power supply.
