Vacuum lifter for mounting
Technical specifications
Inquire now
DSMH4 - 24V-8500
Short description
Meets the requirements for site operation according to DIN EN 13155. The DSMH4 - 24V-8500 can be combined with our counterweight systems. The DSMH4 - 24V-8500 can be combined with many special suction frames
Filter area
Dual circuit system
4 vacuum circuits, independent of each other
Suction pad
32 pieces, type 400K
Extensions
2 piece
Load capacity
7200 kg with 26 suction cups, without extensions 8500 kg with 32 suction cups, with 4 extensions
Turn
360° electric
Sway
90° hydraulic
Power supply
2 pieces 12V battery mains-independent with integrated charger
Furnishing
- Voltage indicator, shows the battery charge level
- Vacuum display, shows the current vacuum level
- Acoustic warning signal when vacuum is undershot
Service
Cable remote control, suction-release with quick-release function, slew up / down, rotate left / right
Own weight
Depending on the attached suction frame
Options
- Radio remote control for suction, release with quick release function
- Slew up/down, rotate left/right
