Vacuum lifter for mounting

Technical specifications

G2 - 12V

Short description

Meets the requirements for site operation according to DIN EN 13155. The G2 - 12V can be combined with many of our mounting devices.

Filter area

up to 450 kg

Dual circuit system

2 vacuum circuits, independent of each other

Suction pad

4 pieces, type 150K

Load capacity

300 kg with 4 suction plates

Power supply

12 V battery mains-independent with integrated charger

Furnishing

Voltage indicator, shows the battery charge level
Vacuum display, shows the current vacuum level
Acoustic warning signal when vacuum is undershot

Service

Radio remote control

Own weight

30 kg

Our expertise: Made to measure

Do you have special requirements due to your particular elements or a demanding environment? Here, too, we can help: In addition to our ready-made solutions, we are also happy to work out a custom-made product exactly for your requirements. In doing so, you can successfully continue your projects with vacuum lifters that have been specially designed for you. Just give us a call and we will discuss the details.
